Signature 3.5 Ton up to 14.3 SEER2 42,000 BTU Split System Heat Pump

$2,239.27

Signature 3.5 Ton up to 14.3 SEER2 42,000 BTU Split System Heat Pump

Available on backorder

SKU: MCAESHS4T4221AA Category: Brand:

Description

The MRCOOL® Signature Series 42k Heat Pump Condenser is a powerful, energy-efficient solution designed to keep your home comfortable all year. With performance ratings of 14.3 SEER2 and 11.7 EER2, it delivers reliable heating and cooling while helping reduce overall energy use and utility bills. Whether you’re facing summer heat or winter chill, this system is built to perform.
Pre-charged with R-454B refrigerant, this model supports modern environmental standards with a lower global warming potential than older refrigerants. The pre-charged design also speeds up installation and reduces labor costs, making it a smart choice for contractors and homeowners alike.
At its core, a single-speed scroll compressor ensures steady, long-lasting performance. Enhanced with inner-groove copper tubing, the system provides faster, more efficient heat transfer. Built-in temperature and pressure sensors offer real-time system monitoring and protection, while an intelligent defrost function prevents frost buildup for smooth operation in cold conditions.
Operating at just 65 decibels, the unit stays quiet enough for residential use, aided by a sound-dampening top. Durability features include a steel louver coil guard, and a wire fan grille, the best for protecting internal components.
The compact design allows flexible installation, and accessible service ports simplify maintenance. Backed by a 10-year limited parts warranty and a limited lifetime compressor guarantee, the MRCOOL® Signature Series 42k Heat Pump Condenser offers lasting comfort and confidence.

Product Resources

Additional information

Weight202 lbs
Dimensions29.14 × 29.14 × 32.875 in
Brand Name

MRCOOL

Series

Signature Series Heat Pump Condenser

Series Ext

ss_td_hp_cnd

Unit Type

Split System Heat Pump Condenser

GTIN

00840255595810

UPC

840255595810

SEER2

14.3

EER2

11.7

HSPF2

7.5

CFM

2950

Tonnage

3.5

Cooling Capacity (BTU)

39000

Heating Capacity (BTU)

39000

Voltage (V)

208/230

Phase

1

Cycle (Hz)

60

Max Fuse Breaker (A)

45

Min Circuit Ampacity (A)

26

Color

Grey

Refrigerant Type

R-454B

Refrigerant Volume (Oz)

119.9

Decibel Rating (Dba)

65

Inverter

No

Min Ambient Cool (F)

59

Min Ambient Heat (F)

5

Max Lineset Length (Ft)

150

Liquid Line Size

3/8

Suction Line Size

3/4

Compressor Motor Type

Scroll

Condenser Fan Motor Type

PSC

Condenser Fan Motor Hp

1/7

UL Listed

Yes

CSA Listed

Yes

ETL Listed

Yes

Energy Star Certified

No

AHRI Certified

Yes

Base Warranty

10 Year Parts, Limited Lifetime Compressor Warranty

Base Parts Warranty

10 Year

Base Compressor Warranty

Limited Lifetime

Contains Electronics

Yes

Contains Chemicals

Yes

Contains Compressed Gas

Yes

Proposition 65 Warning

Yes

Row Number

560

Price

2239.27

Works With

Signature Series Multi-Position or Stud Mount Air Handlers

Net Depth (In)

29.14

Net Height (In)

32.875

Net Width (In)

29.14

Net Weight

202

Gross Depth (In)

30.3

Gross Height (In)

34.8

Gross Width (In)

30.3

Gross Weight (Lbs)

212
